EspañolUniversal clamp on a metal tripod stand, 18-33
#Universal clamps (high base "tripod")
Consists of two independent products: a durable polyurethane clamp and a metal stand (tripod). The clamp can be detached from the stand at any time if it is not needed. Or complete a stand with a polyurethane clamp of a different diameter.
Thanks to the design of the stand, it is convenient to fix the tool on an uneven surface at the desired angle (for example, on the body of a snowmobile).
The original height of the metal tripod stand is 75 mm. The clamp is installed on it at an angle of about 12 degrees. Each tripod post has three mounting holes and additional notches for easy folding. During installation, the height of the stand can be adjusted between 5 and 75 mm.
Fastening made of elastic polyurethane does not damage the tool, it tolerates stretching and repeated bending well without destruction. Does not absorb dirt, easy to clean. Oil and petrol resistant.
The frost resistance and weather resistance of the fastener allows it to be used for transportation and storage of the tool both inside and outside the vehicle.
| Description | D = 18 - 22 mm |
| Applicability | For the barrel of a single-barreled smooth-bore weapon and tool handles |
| Materials | Polyurethane, metal |
| Applicable diameter range | 18-33 mm |
| Manufacturer | LLC Polyurethan |
| Country of production | Russia |
| Weight | 0.155 kg |
| Package size | 110×135×50 mm |
| D1 | 26 mm |
| H1 | 71 mm |
| H2 | 20 mm |
| H3 | 84 mm |
| D1 | 1.0236 ″ |
| H1 | 2.7953 ″ |
| H2 | 0.7874 ″ |
| H3 | 3.3071 ″ |
The distance from the surface and the angle of inclination are adjustable during installation. Each tripod stand has three mounting holes and additional notches for convenient folding. <br> Fastened with screws, self-tapping screws.
| Mounting Kit | Not included |
| Number of mounting holes | 3 |
Installation will be easier with these items
